PCBNR/L P-Type External Turning Tool Holder (75° KAPR) - for CNMG/CNMA/CNMM Inserts
This high-performance P-Type External Turning Tool Holder features a robust Lever Lock System designed for heavy-duty machining. With a 75° Tool Cutting Edge Angle (KAPR), it ensures excellent chip evacuation and stability. Ideally suited for Turning Tool Holder applications using standard CNMG negative inserts.
Contact our sales team to discover all of your pricing options.
The PCBNR/L series is a classic External Turning Tool Holder widely used in lathe operations for outer diameter (OD) and face turning. This tool holder utilizes the P-type Lever Lock System, which generates strong clamping force through a lever mechanism, securely holding the insert in the pocket. This design not only guarantees high stability during machining but also eliminates the need for a top clamp, preventing chip obstruction—making it perfect for heavy cutting with large depths of cut and high feed rates.
Key Features:
-
75° Tool Cutting Edge Angle (KAPR): Provides a balanced distribution of cutting forces, suitable for general OD and facing operations.
-
Lever Lock System: Enables rapid insert indexing and high repeatability. The absence of an upper clamp ensures smooth chip flow.
-
Wide Compatibility: Specifically designed as a CNMG Insert Tool Holder, compatible with various double-sided 80° diamond inserts (negative) such as CN..1204.., CN..1606.., and CN..1906…
-
Versatile Specifications: Available in shank sizes ranging from 20mm to 40mm, meeting diverse cnmg insert tool holder specification requirements for different lathes.
-
Applications: Suitable for roughing to semi-finishing of steel, stainless steel, cast iron, and heat-resistant alloys.
Product Specification Table
| Model | Size a (mm) | Size b (mm) | Size L (mm) | Size h (mm) | Size f (mm) | Size e (mm) | Inserts |
|---|---|---|---|---|---|---|---|
| PCBNR/L2020K12C | 20 | 20 | 125 | 20 | 17 | 27 | CN..1204.. |
| PCBNR/L2525M12C | 25 | 25 | 150 | 25 | 22 | 27 | CN..1204.. |
| PCBNR/L3232P12C | 32 | 32 | 170 | 32 | 27 | 32 | CN..1204.. |
| PCBNR/L2525M16C | 25 | 25 | 150 | 25 | 22 | 33 | CN..1606.. |
| PCBNR/L3232P16C | 32 | 32 | 170 | 32 | 27 | 33 | CN..1606.. |
| PCBNR/L4040S16C | 40 | 40 | 250 | 40 | 35 | 33 | CN..1606.. |
| PCBNR/L3232P19C | 32 | 32 | 170 | 32 | 27 | 38 | CN..1906.. |
| PCBNR/L4040S19C | 40 | 40 | 250 | 40 | 35 | 38 | CN..1906.. |
| PCBNR/L4040S2507C | 40 | 40 | 250 | 40 | 35 | 50 | CN..2507.. |
| PCBNR/L4040S2509C | 40 | 40 | 250 | 40 | 35 | 50 | CN..2509.. |
